Increased Efficiency of Orthodontic Treatment Through Ancillary Surgical Procedures Flavio Uribe, DDS, MDS

Start Discussion
By Flavio Uribe, DDS, MDS

One of the most important goals in health care is to deliver effective and efficient therapies. Effectiveness of treatment involves achieving the desired result, while efficiency accounts for the time and resources required to obtain the expected outcome. Efficiency of treatment has become one of the major aims in health care. The National Institute of Health (NIH) has taken keen interest in this type of research as potential health-care costs may be reduced. In orthodontics some interest has also surged in this area. An example is the randomized clinical trials evaluating two phases vs. one phase treatment in Class II malocclusions.

The feasibility of moving teeth faster is another area of interest related to efficiency that is emerging in orthodontics. This would have the potential advantage of reducing treatment times, with the inherent benefit of eliminating or reducing the negative sequelae often associated with extended treatment times i.e.,root resorption, periodontal problems, and white spot lesions. In addition, modern society might also have keen interest in shorter treatment times as the notion of instant gratification might be a new expectation, especially when treatment is associated with aesthetic procedures.

The possibilities of attaining faster orthodontic tooth movement are closely tied to the word biomechanics. Hence, the biology could be altered or the mechanics adjusted. Certainly, a combination of both is also possible. When the biology is considered, interesting results have been produced in basic science research using animal models. Different molecules have been proven to be efficient in targeting the osteoclast, which in turn is responsible for resorbing the bone in order to ensue faster orthodontic tooth movement. However, as King summarized, "We are still far from the option of clinically delivering biological substances to enhance orthodontic treatment. These substances have to be proven safe, localized and self-limiting in action."¹

The other aspect that can be targeted is the mechanical component. In this area some clinicians have claimed that the use of "frictionless appliances" might provide efficiency in treatment. This claim remains unsubstantiated as the majority of clinical research in this area has failed to show this efficiency.²

Furthermore, it could be difficult to explain how an appliance with less friction translates biologically into faster orthodontic tooth movement. Overall, the more pertinent question that remains to be answered is the magnitude of the optimal force needed to achieve the highest efficiency.

The consensus has been that a low continuous force could be the most physiologic way to move teeth. However, it is still not clear what a low force or a high force really mean. A systematic review showed that the magnitude of an optimal force (most effective) is unknown.³ Some experimental approaches that have been attempted in relation to force delivery are intermittent vs. continuous forces and the application of higher initial forces followed by forces of lesser magnitude. It seems that a continuous force could be most effective; however, optimal force magnitudes might vary between types of tooth movements and individuals.

The third option to attain faster tooth movement targets both the biology and the mechanics. The biology is modulated through a mechanical or physical alteration of the bone, and an applied orthodontic force is superposed. Surgical procedures such as corticotomies and osteotomies, vibration, and low energy lasers belong to this category. The two latter ones have been applied recently, mostly in basic science models. The results have been positive, reporting efficiency in orthodontic tooth movement. On the other hand, the two localized surgical procedures have been approached clinically for many years, and only until recently they have been gaining increased attention.

Corticotomies
A corticotomy is the procedure by which a flap is elevated and the cortical bone is scored with a bur or piezosurgical instrument approximately 1-2mm in depth. This method was described more than five decades ago and used in conjunction with orthodontic appliances in order to facilitate orthodontic tooth movement.4 The original description consisted of interproximal grooves between adjacent teeth with a sub-apical corticotomy. The technique was modified by Wilcko, et. al., who added a particulate bone allograft over the alveolar decorticated surfaces. The technique was labeled accelerated osteogenic orthodontics (AOO). The benefits claimed were increased alveolar bone width, which allowed to labially displace the teeth, better stability, and increased efficiency in orthodontic tooth movement.5,6

Animal Studies
The increased efficiency in tooth movement has been related to a series of biological effects that are precipitated by the surgical cuts. This phenomenon has been described as a regional accelerated phenomenon (RAP) that might increase the bone turnover, thus facilitating the expedited tooth movement. Animal studies using this technique have shown contradictory results. A study by Lee compared the speed in tooth movement in rats between coticotomy-assisted orthodontics, osteotomyassisted orthodontics, and orthodontics alone. They found no significant difference between groups in a three-week period.7 Iino found in Beagle dogs that the speed of tooth movement was enhanced in the first two weeks; however, the rate of tooth movement was not significantly different thereafter (from two to four weeks).8 Two more studies, one in dogs and another in foxhounds also found increased rates of tooth movement.9,10

The surgical technique of the corticotomies has evolved to become less extensive. It has been proposed that limiting the corticotomy to circumscribed indentiations of the cortical bone might suffice to establish a biological response necessary for increased bone turnover, thus enhanced tooth movement. It has been proposed that the flap procedure might be omitted and small interproximal vertical incisions performed with a reinforced scalpel on the labial and lingual mucosa might be sufficient to trigger accelerated tooth movement. An animal study in cats showed expedited tooth movement with this procedure named corticision.11 A similar clinical application of this method was published recently, where a small interproximal vertical incision was performed on the buccal aspect of the gingiva on both the maxillary and mandiublar arch. In addition, a piezotome was used to score the cortical bone through the gingival incisions. Bone graft material was packed in the anterior region where the alveolar bone width was considered to be narrow. The authors named the technique piezo incision and documented a case report of an adult patient with mild crowding whose malocclusion was corrected in a very short period of time.12

Clinical Applications of Corticotomies
Several applications have been published using corticotomies as an adjunct to orthodontic treatment. The most common description has been for the treatment of crowding. However, it has been also described for the intrusion of molars, treatment of bimaxillary protrusion, molar distalization and canine impactions.7,13-15 This technique is being explored currently at the University of Connecticut for molar protraction in patients with congenitally missing second premolars, or first molars lost to caries. The technique is being combined with skeletal anchorage to evaluate if the time to achieve a significant amount of molar protraction might be reduced. Overall, it is important to highlight that the treatment times seem to be reduced with corticotomies in all clinical applications. However, a word of caution is needed as the majority of evidence available is based on few case reports of the technique.

Osteotomies
Another surgical intervention that has been explored clinically is the complete segmentation of a tooth or group of teeth through the cortical and medullary bone. This technique relies in the application of heavy orthopedic forces after the segmentation. The force magnitude applied is in the range of 800 grams, or higher orthopedic forces delivered with osseous distraction devices. This approach has been applied mostly in the expedited treatment of patients with bimaxillary protrusion undergoing four premolar extractions.

Two basic techniques have been described for the space closure in these patients undergoing four premolar extractions. In one approach, the canine is distracted distally in a one to two week period, and then the incisors are moved lingually through traditional orthodontic forces.16,17 A second approach is the osteotomy of the whole anterior canine to canine segment in the maxilla, and the application of a heavy orthodontic retraction force. This is done in combination with a lower subapical segmental osteotomy of the canine-to-canine segment of the mandible which is immediately set back into position. Treatment times for these patients have reported to be approximately 10 months.18

Another application for osteotomies has been explored in the treatment of ankylosed central incisors. This has been accomplished through interproximal segmentation of the bone fragment containing the central incisor, and the application of a distraction device or a heavy orthodontic force.19-21 Recently, at the University of Connecticut, this technique was successfully applied to an ankylosed canine. The procedure was made through a careful approach using piezosurgery to prevent injury to the canine and adjacent roots. The bony impacted canine was brought into the arch in three weeks with a heavy orthodontic force. Although this is a promising option for ankylosed canines, it is limited to those that are positioned in such location where surgical access is possible without a significant risk of affecting the surrounding teeth and anatomic structures.

Surgery First
A final permutation of the osteotomies technique is related to the concept of surgery first. This concept was introduced in the early 90s with the idea of eliminating the presurgical orthodontic phase in patients undergoing orthognathic surgery.22 Recently, Nagasaki reintroduced the concept and applied it to a Class III patient where the presurgical phase was omitted. A case report described this technique, which was facilitated by skeletal anchorage. The skeletal anchorage provided by four plates placed at the time of surgery, offered the biomechanical advantage to obtain significant orthodontic movements in the postsurgical phase. The total treatment time for this patient was only one year, albeit including significant maxillary distalization.23 This significantly contrasts with the recent prospective study of orthognathic surgery of patients in the United Kingdom where the average treatment time was 32 months, including a presurgical phase of 12-18 months.24

The advantages of the surgery first technique were an immediate correction of the skeletal deformity, the elimination of the soft tissue imbalance, which might facilitate the orthodontic movements, and the expedited treatment time. They postulated that this reduced treatment time might be related to the RAP phenomenon triggered by the surgical osteotomies.

Recently, at the University of Connecticut and at the Instituto de Ciencias de la Salud the surgery first technique has been simplified.24-26 Instead of placing a passive wire at the time of surgery, a NiTi aligning wire is placed in both arches just before the surgical procedure. By doing so, it eliminated the complicated task of bending a passive rectangular stainless steel wire to a malaligned arch. In addition, the window of the RAP might be maximized as the tooth movement is occurring immediately after surgery. The technique has been applied primarily to the treatment of Class III malocclusions with significant reduction in treatment times (Figures 1-5). This technique appears to be promising as patients are greatly satisfied with the short treatment times and the immediate "makeover," without the accentuation of the deformity often observed after the presurgical decompensation phase.

Conclusion
A great interest has sparked in the profession in expediting tooth movement. Although biological intervention with different molecules will most likely occur in the future, at the current time only surgical procedures have shown some promise in enhancing the speed of tooth movement. Some of these procedures are corticotomies and osteotomies in conjunction to traditional orthodontic appliances. Finally, the surgery first concept might become mainstream in orthognathic surgery as significant reduction in treatment times and immediate patient gratification are tempting advantages of the technique.

With permission from: Uribe, F., Cutrera, A., Villegas, C., Nanda, R. Corticotomies and Other Adjuncts to Enhance Orthodontic Tooth Movement in: McNamara JA Jr, Hatch N, Kapila SD (eds).Effective and efficient orthodontic tooth movement: An evidenced-based approach. Monograph 48, Craniofacial Growth Series, Department of Orthodontics and Pediatric Dentistry and Center for Human Growth and Development, The University of Michigan, Ann Arbor, in press, 2011.

References:
  1. King G. Biomedicine in orthodontics: from tooth movement to facial growth. Orthod Craniofac Res 2009;12:53-58.
  2. Turpin DL. In-vivo studies offer best measure of self-ligation. American Journal of Orthodontics and Dentofacial Orthopedics 2009;136:141-142.
  3. Ren Y, Maltha JC, Kuijpers-Jagtman AM. Optimum force magnitude for orthodontic tooth movement: a systematic literature review. Angle Orthod 2003;73:86-92.
  4. Kole H. Surgical operations on the alveolar ridge to correct occlusal abnormalities. Oral Surg Oral Med Oral Pathol 1959;12:515-529.
  5. Wilcko MT, Wilcko WM, Bissada NF. An evidence-based analysis of periodontally accelerated orthodontic and osteogenic techniques: a synthesis of scientific perspectives. Seminars in Orthodontics 2008;14:305-316.
  6. Wilcko WM, Wilcko T, Bouquot JE, Ferguson DJ. Rapid orthodontics with alveolar reshaping: two case reports of decrowding. Int J Periodontics Restorative Dent 2001;21:9-19.
  7. Lee JK, Chung KR, Baek SH. Treatment outcomes of orthodontic treatment, corticotomy-assisted orthodontic treatment, and anterior segmental osteotomy for bimaxillary dentoalveolar protrusion. Plast Reconstr Surg 2007;120:1027-1036.
  8. Iino S, Sakoda S, Ito G, Nishimori T, Ikeda T, Miyawaki S. Acceleration of orthodontic tooth movement by alveolar corticotomy in the dog. Am J Orthod Dentofacial Orthop 2007;131:448 e441-448.
  9. Sanjideh PA, Rossouw PE, Campbell PM, Opperman LA, Buschang PH. Tooth movements in foxhounds after one or two alveolar corticotomies. Eur J Orthod 2009. 10. Mostafa YA, Mohamed Salah Fayed M, Mehanni S, ElBokle NN, Heider AM. Comparison of corticotomyfacilitated vs standard tooth-movement techniques in dogs with miniscrews as anchor units. Am J Orthod Dentofacial Orthop 2009;136:570-577.
  10. Kim SJ, Park YG, Kang SG. Effects of Corticision on paradental remodeling in orthodontic tooth movement. Angle Orthod 2009;79:284-291.
  11. Dibart S, Sebaoun JD, Surmenian J. Piezocision: a minimally invasive, periodontally accelerated orthodontic tooth movement procedure. Compend Contin Educ Dent 2009;30:342-344, 346, 348-350.
  12. Fischer TJ. Orthodontic treatment acceleration with corticotomy-assisted exposure of palatally impacted canines. Angle Orthod 2007;77:417-420.
  13. Spena R, Caiazzo A, Gracco A, Siciliani G. The use of segmental corticotomy to enhance molar distalization. J Clin Orthod 2007;41:693-699.
  14. Hwang HS, Lee KH. Intrusion of overerupted molars by corticotomy and magnets. Am J Orthod Dentofacial Orthop 2001;120:209-216.
  15. Iseri H, Kisnisci R, Bzizi N, Tuz H. Rapid canine retraction and orthodontic treatment with dentoalveolar distraction osteogenesis. Am J Orthod Dentofacial Orthop 2005;127:533-541; quiz 625.
  16. Liou EJ, Huang CS. Rapid canine retraction through distraction of the periodontal ligament. Am J Orthod Dentofacial Orthop 1998;114:372-382.
  17. Chung KR, Kim SH, Lee BS. Speedy surgical-orthodontic treatment with temporary anchorage devices as an alternative to orthognathic surgery. Am J Orthod Dentofacial Orthop 2009;135:787-798.
  18. Dolanmaz D, Karaman AI, Pampu AA, Topkara A. Orthodontic Treatment of an Ankylosed Maxillary Central Incisor through Osteogenic Distraction. Angle Orthod 2010;80:391-395.
  19. Kinzinger GS, Janicke S, Riediger D, Diedrich PR. Orthodontic fine adjustment after vertical callus distraction of an ankylosed incisor using the floating bone concept. Am J Orthod Dentofacial Orthop 2003;124:582-590.
  20. Kofod T, Wurtz V, Melsen B. Treatment of an ankylosed central incisor by single tooth dento-osseous osteotomy and a simple distraction device. Am J Orthod Dentofacial Orthop 2005;127:72-80.
  21. Brachvogel P, Berten JL, Hausamen JE. [Surgery before orthodontic treatment: a concept for timing the combined therapy of skeletal dysgnathias]. Dtsch Zahn Mund Kieferheilkd Zentralbl 1991;79:557-563.
  22. Nagasaka H, Sugawara J, Kawamura H, Nanda R. "Surgery first" skeletal Class III correction using the Skeletal Anchorage System. J Clin Orthod 2009;43:97-105.
  23. O'Brien K, Wright J, Conboy F, Appelbe P, Bearn D, Caldwell S et al. Prospective, multi-center study of the effectiveness of orthodontic/orthognathic surgery care in the United Kingdom. Am J Orthod Dentofacial Orthop 2009;135:709-714.
  24. Uribe F, Villegas C, Nanda R. Surgically enhancing the speed of tooth movement: can we alter the biology. In: Kapila S, McNamara J, editors. Surgical Enhancement to Orthodontic Treatment. Ann Arbor: Unversity of Michigan; In Press.
  25. Villegas C, Uribe F, Nanda R. Expedited correction of a significant dentofacial asymmetry using the "surgery first" approach. Journal of Clinical Orthodontics, In Press.
Author’s Bio
Dr. Flavio Uribe received his Master's degree and Certificate in Orthodontics from the University of Connecticut after receiving the DDS degree from CES University in Medellin, Colombia. He also completed a three- year residency and fellowship in General Dentistry at the University of Connecticut. Dr. Uribe is a full-time associate professor and program director in the Division of Orthodontics at the University of Connecticut and has authored and coauthored numerous chapters and articles in peer-reviewed journals.
